This page lets you edit / insert a single QoS Control Entry at a time. A QCE consists of several parameters. These
parameters vary according to the Frame Type that you select.
Port Members: Check the checkbox to include a port in the QCL entry. By default all ports are included .
Key Parameters: Key configuration is described below:
DMAC (Destination MAC address): Possible values are 'Unicast', 'Multicast', 'Broadcast', 'Specific' (xx-xx-xx-xx-
xx-xx) or 'Any'.
SMAC (Source MAC address): xx-xx-xx-xx-xx-xx or 'Any'.
Tag: Value of Tag field can be 'Untagged', 'Tagged', 'C-Tagged', 'S-Tagged' or 'Any'.
VID: Valid value of VLAN ID can be any value in the range 1-4095 or 'Any'; enter either a specific value or a range
of VIDs.
PCP: Valid value PCP are specific (0, 1, 2, 3, 4, 5, 6, 7) or range (0-1, 2-3, 4-5, 6-7, 0-3, 4-7) or 'Any'.
DEI: Valid value of DEI can be '0', '1' or 'Any'.
Inner Tag: Value of Inner Tag field can be 'Untagged', 'Tagged', 'C-Tagged', 'S-Tagged' or 'Any'.
Inner VID: Valid value of Inner VLAN ID can be any value in the range 1-4095 or 'Any'; user can enter either a
specific value or a range of VIDs.
Inner PCP: Valid value of Inner PCP are specific (0, 1, 2, 3, 4, 5, 6, 7) or range (0-1, 2-3, 4-5, 6-7, 0-3, 4-7) or
'Any'.
Inner DEI: Valid value of Inner DEI can be '0', '1' or 'Any'.
Frame Type: Can have one of these values: Any, EtherType, LLC, SNAP, IPv4, or IPv6 as described below.
1. Any: Allow all types of frames.
2. EtherType: Valid Ether Type can be 0x600-0xFFFF excluding 0x800(IPv4) and 0x86DD(IPv6) or 'Any'.
3. LLC: The Logical Link Control (LLC) data comm protocol layer is the upper sublayer of layer 2 of the OSI
model.
DSAP Address: Valid DSAP (Destination Service Access Point) can vary from 0x00 to 0xFF or 'Any'.
SSAP Address: Valid SSAP (Source Service Access Point) can vary from 0x00 to 0xFF or 'Any'.
Control: Valid Control field can vary from 0x00 to 0xFF or 'Any'.
4. SNAP: PID Valid PID(a.k.a Ether Type) can be 0x0000-0xFFFF or 'Any'.
5. IPv4: Protocol: IP protocol number: (0-255, 'TCP' or 'UDP') or 'Any'.
Source IP: Specific Source IP address in value/mask format or 'Any'. IP and Mask are in the format
x.y.z.w where x, y, z, and w are decimal numbers between 0 and 255. When Mask is converted to a 32-
bit binary string and read from left to right, all bits following the first zero must also be zero.
Destination IP: Specific Destination IP address in value/mask format or 'Any'.
IP Fragment: IPv4 frame fragmented option: 'Yes', 'No' or 'Any'.
DSCP: Diffserv Code Point value (DSCP): It can be a specific value, range of values or 'Any'. DSCP
values are in the range 0-63 including BE, CS1-CS7, EF or AF11-AF43.
Sport: Source TCP/UDP port:(0-65535) or 'Any', specific or port range applicable for IP protocol
UDP/TCP.
Dport: Destination TCP/UDP port:(0-65535) or 'Any', specific or port range applicable for IP protocol
UDP/TCP.
6. IPv6: Protocol: IP protocol number: (0-255, 'TCP' or 'UDP') or 'Any'.
Source IP: 32 LS bits of IPv6 source address in value/mask format or 'Any'.
Destination IP: Specific Destination IP address in value/mask format or 'Any'.
