Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 136
DSCP: Diffserv Code Point value (DSCP): It can be a specific value, range of values or 'Any'. DSCP
values are in the range 0-63 including BE, CS1-CS7, EF or AF11-AF43.
Sport: Source TCP/UDP port:(0-65535) or 'Any', specific or port range applicable for IP protocol
UDP/TCP.
Dport: Destination TCP/UDP port:(0-65535) or 'Any', specific or port range applicable for IP protocol
UDP/TCP.
Action Parameters:
Queue Priority: Class of Service: (0-7) or 'Default'.
DPL: Drop Precedence Level: (0-3) or 'Default'.
DSCP: (0-63, BE, CS1-CS7, EF or AF11-AF43) or 'Default'.
PCP: (0-7) or 'Default'. Note: PCP and DEI cannot be set individually.
DEI: (0-1) or 'Default'.
Policy: ACL Policy number (0-127) or 'Default' (empty field).
'Default' means that the default classified value is not modified by this QCE.
Buttons
Apply: Click to save the configuration and move to main QCL page.
Reset: Click to undo any changes made locally and revert to previously saved values.
Cancel: Return to the previous page without saving the configuration change.
Modification Buttons
You can modify each QCE (QoS Control Entry) in the table using these buttons:
: Insert new QCE before the current row.
: Edit QCE.
: Move QCE up the list.
: Move QCE down the list.
: Delete QCE.
: The lowest plus sign adds a new QCE to the end of the QCE list.
Messages:
PCP and DEI cannot be set individually!
