Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 216
Port Counters
EAPOL Counters: These supplicant frame counters are available for the following administrative states:
• Force Authorized
• Force Unauthorized
• Port-based 802.1X
• Single 802.1X
• Multi 802.1X
Direction
Name
IEEE Name
Description
RX Total dot1xAuthEapolFramesRx
The number of valid EAPOL frames of
any type that have been received by
the switch.
RX Response ID dot1xAuthEapolRespIdFramesRx
The number of valid EAPOL Response
Identity frames that have been received
by the switch.
RX Responses dot1xAuthEapolRespFramesRx
The number of valid EAPOL response
frames (other than Response Identity
frames) that have been received by the
switch.
RX Start dot1xAuthEapolStartFramesRx
The number of EAPOL Start frames
that have been received by the switch.
RX Logoff dot1xAuthEapolLogoffFramesRx
The number of valid EAPOL Logoff
frames that have been received by the
switch.
RX Invalid Type dot1xAuthInvalidEapolFramesRx
The number of EAPOL frames that
have been received by the switch in
which the frame type is not recognized.
RX Invalid Length dot1xAuthEapLengthErrorFramesRx
The number of EAPOL frames that
have been received by the switch in
which the Packet Body Length field is
invalid.
TX Total dot1xAuthEapolFramesTx
The number of EAPOL frames of any
type that have been transmitted by the
switch.
TX Request ID dot1xAuthEapolReqIdFramesTx
The number of EAPOL Request Identity
frames that have been transmitted by
the switch.
TX Requests dot1xAuthEapolReqFramesTx
The number of valid EAPOL Request
frames (other than Request Identity
frames) that have been transmitted by
the switch.
