Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 217
Backend Server Counters: These backend (RADIUS) frame counters are available for the following
administrative states:
• Port-based 802.1X
• Single 802.1X
• Multi 802.1X
• MAC-based Auth.
RX
Access
Challenges
dot1xAuthBackendAccessChallenges
802.1X-based: Counts the number of
times that the switch receives the first
request from the backend server following
the first response from the supplicant.
Indicates that the backend server has
communication with the switch.
MAC-based: Counts all Access
Challenges received from the backend
server for this port (left-most table) or
client (right-most table).
RX Other Requests
dot1xAuthBackendOtherRequestsTo
Supplicant
802.1X-based: Counts the number of
times that the switch sends an EAP
Request packet following the first to the
supplicant. Indicates that the backend
server chose an EAP-method.
MAC-based: Not applicable.
802.1X- and MAC-based: Counts the
number of times that the switch receives a
success indication. Indicates that the
supplicant/client has successfully
authenticated to the backend server.
RX
Auth.
Successes
dot1xAuthBackendAuthSuccesses
802.1X- and MAC-based:
Counts the number of times that the
switch receives a failure message. This
indicates that the supplicant/client has not
authenticated to the backend server.
RX Auth. Failures dot1xAuthBackendAuthFails
802.1X-based: Counts the number of
times that the switch attempts to send a
supplicant's first response packet to the
backend server. Indicates the switch
attempted communication with the
backend server. Possible retransmissions
TX Responses dot1xAuthBackendResponses
MAC-based: Counts all the backend
server packets sent from the switch
towards the backend server for a given
port (left-most table) or client (right-most
table). Possible retransmissions are not
To Next Page
