Lantronix SISPM1040 L3 Series User Manual

Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 218
Last Supplicant/Client Info: Information about the last supplicant/client that attempted to authenticate. This
information is available for the following administrative states:
• Port-based 802.1X
• Single 802.1X
• Multi 802.1X
• MAC-based Auth.
Last Supplicant/Client Info :
Name
IEEE Name
Description
MAC Address
dot1xAuthLastEapolFrameSource
The MAC address of the last supplicant/client.
VLAN ID -
The VLAN ID on which the last frame from the last
supplicant/client was received.
Version dot1xAuthLastEapolFrameVersion
802.1X-based: The protocol version number carried in
the most recently received EAPOL frame.
MAC-based: Not applicable.
Identity -
802.1X-based: The user name (supplicant identity)
carried in the most recently received Response Identity
EAPOL frame.
MAC-based: Not applicable.
Selected Counters
Selected Counters: The Selected Counters table is visible when the port is in one of the following administrative
states:
• Multi 802.1X
• MAC-based Auth.
The table is identical to and is placed next to the Port Counters table, and will be empty if no MAC address is
currently selected. To populate the table, select one of the attached MAC Addresses from the section below.
Attached MAC Addresses
Identity: Shows the identity of the supplicant, as received in the Response Identity EAPOL frame. Clicking the
link causes the supplicant's EAPOL and Backend Server counters to be shown in the Selected Counters table. If
no supplicants are attached, it shows No supplicants attached. This column is not available for MAC-based Auth.
MAC Address: For Multi 802.1X, this column holds the MAC address of the attached supplicant.
For MAC-based Auth., this column holds the MAC address of the attached client.
Clicking the link causes the client's Backend Server counters to be shown in the Selected Counters table. If no
clients are attached, it shows No clients attached.
VLAN ID: This column holds the VLAN ID that the corresponding client is currently secured through the Port
Security module.
State: The client can either be authenticated or unauthenticated. In the authenticated state, it is allowed to
forward frames on the port, and in the unauthenticated state, it is blocked. As long as the backend server hasn't
successfully authenticated the client, it is unauthenticated. If an authentication fails for one or the other reason,
the client will remain in the unauthenticated state for Hold Time seconds.
Last Authentication: Shows the date and time of the last authentication of the client (successful as well as
unsuccessful).
