Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 260
ARP Parameters: The ARP parameters can be configured when Frame Type "ARP" is selected.
ARP/RARP: Specify the available ARP/RARP opcode (OP) flag for this ACE.
Any: No ARP/RARP OP flag is specified. (OP is "don't-care".)
ARP: Frame must have ARP opcode set to ARP.
RARP: Frame must have RARP opcode set to RARP.
Other: Frame has unknown ARP/RARP Opcode flag.
Request/Reply: Specify the available Request/Reply opcode (OP) flag for this ACE.
Any: No Request/Reply OP flag is specified. (OP is "don't-care".)
Request: Frame must have ARP Request or RARP Request OP flag set.
Reply: Frame must have ARP Reply or RARP Reply OP flag.
Sender IP Filter: Specify the sender IP filter for this ACE.
Any: No sender IP filter is specified. (Sender IP filter is "don't-care".)
Host: Sender IP filter is set to Host. Specify the sender IP address in the SIP Address field that appears.
Network: Sender IP filter is set to Network. Specify the sender IP address and sender IP mask in the SIP
Address and SIP Mask fields that appear.
Sender IP Address: When "Host" or "Network" is selected for the sender IP filter, you can enter a specific sender
IP address in dotted decimal notation. Notice the invalid IP address configuration is acceptable too, for example,
0.0.0.0. Normally, an ACE with invalid IP address will explicitly adding deny action.
Sender IP Mask: When "Network" is selected for the sender IP filter, you can enter a specific sender IP mask in
dotted decimal notation.
Target IP Filter: Specify the target IP filter for this specific ACE:
Any: No target IP filter is specified. (Target IP filter is "don't-care".)
Host: Target IP filter is set to Host. Specify the target IP address in the Target IP Address field that
appears. Network: Target IP filter is set to Network. Specify the target IP address and target IP mask in
the Target IP Address and Target IP Mask fields that appear.
Target IP Address: When "Host" or "Network" is selected for the target IP filter, you can enter a specific target IP
address in dotted decimal notation. Notice the invalid IP address configuration is acceptable too, for example,
0.0.0.0. Normally, an ACE with invalid IP address will explicitly adding deny action.
Target IP Mask: When "Network" is selected for the target IP filter, you can enter a specific target IP mask in
dotted decimal notation.
ARP Sender MAC Match: Specify whether frames can hit the action according to their sender hardware address
field (SHA) settings:
0: ARP frames where SHA is not equal to the SMAC address.
1: ARP frames where SHA is equal to the SMAC address.
Any: Any value is allowed ("don't-care").
RARP Target MAC Match: Specify whether frames can hit the action according to their target hardware address
field (THA) settings:
0: RARP frames where THA is not equal to the target MAC address.
1: RARP frames where THA is equal to the target MAC address.
Any: Any value is allowed ("don't-care").
