Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 259
MAC Parameters
SMAC Filter: (Only displayed when the frame type is Ethernet Type or ARP.) Specify the source MAC filter for
this ACE:
Any: No SMAC filter is specified. (SMAC filter status is "don't-care".)
Specific: If you want to filter a specific source MAC address with this ACE, choose this value. A field for
entering an SMAC value appears.
SMAC Value: When "Specific" is selected for the SMAC filter, you can enter a specific source MAC address. The
legal format is "xx-xx-xx-xx-xx-xx" or "xx.xx.xx.xx.xx.xx" or "xxxxxxxxxxxx" (x is a hexadecimal digit). A frame that
hits this ACE matches this SMAC value.
DMAC Filter: Specify the destination MAC filter for this ACE:
Any: No DMAC filter is specified. (DMAC filter status is "don't-care".)
MC: Frame must be multicast.
BC: Frame must be broadcast.
UC: Frame must be unicast.
Specific: If you want to filter a specific destination MAC address with this ACE, choose this value. A field
for entering a DMAC value appears.
DMAC Value: When "Specific" is selected for the DMAC filter, you can enter a specific destination MAC address.
The legal format is "xx-xx-xx-xx-xx-xx" or "xx.xx.xx.xx.xx.xx" or "xxxxxxxxxxxx" (x is a hexadecimal digit). A frame
that hits this ACE matches this DMAC value.
VLAN Parameters
802.1Q Tagged: Specify whether frames can hit the action according to 802.1Q tagged. The allowed values are:
Any: Any value is allowed ("don't-care"). The default value is "Any".
Enabled: Tagged frame only.
Disabled: Untagged frame only.
VLAN ID Filter: Specify the VLAN ID filter for this ACE:
Any: No VLAN ID filter is specified. (VLAN ID filter status is "don't-care".)
Specific: If you want to filter a specific VLAN ID with this ACE, choose this value. A field for entering a
VLAN ID number appears.
VLAN ID: When "Specific" is selected for the VLAN ID filter, you can enter a specific VLAN ID number. The
allowed range is 1 to 4095. A frame that hits this ACE matches this VLAN ID value.
Tag Priority: Specify the tag priority for this ACE. A frame that hits this ACE matches this tag priority. The
allowed number range is 0 to 7 or range 0-1, 2-3, 4-5, 6-7, 0-3 and 4-7. The value Any means that no tag priority
is specified (tag priority is "don't-care".)
