Ring Id: The Ring ID is used, along with the control VLAN, to identify R-APS PDUs as belonging to a particular
ring.
Node Id: The Node ID used inside the R-APS specific PDU to uniquely identify this node (switch) on the ring.
Level: MD/MEG Level of R-APS PDUs we transmit.
Control VLAN: The VLAN on which R-APS PDUs are transmitted and received on the ring ports.
Control PCP: The PCP value used in the VLAN tag of the R-APS PDUs.
Rev: Revertive (true) or Non-revertive (false) mode.
Guard: Guard time in ms. Valid range is 10 - 2000 ms.
WTR: "Wait-to-Restore time in seconds. Valid range is 1 - 720 sec.
Hold Off: Hold off time in ms. Value is rounded down to 100ms precision. Valid range is 0 - 10000 ms.
Enable: The administrative state of this APS ERPS. Checked means it is functioning normally and unchecked
means it is not functioning.
Oper: The operational state of an ERPS instance:
• : Active:
• : Disabled or Internal error.
Warning: Operational warnings of ERPS instance:
• : No warnings
• : There are warnings, use tooltip to see.
Configuration Buttons : You can modify each ERPS in the table using these buttons:
Add: Adds new ERPS.
Edit: Edits the ERPS row.
Delete: Deletes the ERPS.
