Device Consoles
Left-click any device icon to display the device consoles for further actions.
Dashboard Console: displays device info and related actions for the device.
Different device types support different function:
If an IP device is recognized as DMS switch, it will support "Upgrade" and "Find Switch" function.
If an IP device is recognized as PoE device, it will support more "Reboot" function in addition to
"Upgrade".
If an IP device is recognized as IP Cam via ONVIF protocol, it will support "Streaming" function.
Device Type: Can be displayed automatically. If an unknown type is detected, you can still select type from a pre-
defined list. Device Types include PC (General PC), IP Camera (General IP Cam), IP Phone (General IP Phone,
Cisco SPA303), AP (General AP), and Others (Mobile Device, General Switch, Internet Gateway, IP PBX, NAS,
Printer, NVR, VMS, Unknown Device).
Device Name: Create your own Device Name or alias for easy management such as, 1F_Lobby_Cam1.
Model Name, MAC Address, IP Address, Subnet Mask, Gateway, PoE Supply and PoE Used are displayed
automatically by DMS.
HTTP Port: Re-assign HTTP port number to the device for better security.
Login: Click the Login Action Icon to log in the device via HTTP for further configuration or status
monitoring.
Upgrade: Click it to upgrade software version.
Find Switch: When this feature is activated, the switch LEDs will all flicker for 15 seconds.
