Diagnostics: Click Diagnostic Action Icon to perform the cable diagnostics, to exam where the
broken cable is, and check if the device connection is alive or not by ping.
 Cable Status:
 Green icon: Cable is connected correctly.
 Red icon: Cable is not connected correctly. User can check the distance info (XX meters) to
identify the broken cable location.
 Connection:
 Green icon: Device is pinged correctly.
 Red icon: Device is not transmitted /receiving data correctly. Which means it might not be
pinged successfully.
Reboot: Click Reboot Action Icon to reboot the device remotely so as recover the device back to its
normal operation.
Streaming: Click Streaming Action Icon to display the video images streaming if the device supports
this feature.
Parent Node: When DMS switch detects more than two IP devices from the same port, switch can't
resolve this IP device's layout, instead, it will show a blank node to present this situation. User can use "Parent
Node" function to adjust layout in Dashboard.
