214603 266 Revision A
b. Press the DISPLAY SELECTOR button (E) on the GSL to display ##.## ##.# REEL IND
19
or press
FAST (C) or SLOW (D) switch.
• The displayed value (##.##) = reel speed (rpm or mph or km/h
18
)
• The displayed value (#.##) = reel index value
c. Press FAST (C) or SLOW (D) until the desired reel index is achieved.
NOTE:
The reel will continue operating at the minimum reel speed setting when the ground speed drops below the
set value.
The cab display module (CDM) display (A) will flash ##.## MIN REEL (RPM or MPH or KPH) prompting you to
change the minimum set-point or increase your ground speed if the total of the ground speed, plus the index
value is LESS THAN the minimum reel speed set-point.
Examples:
• Windrower is operating at 13 km/h (8 mph) with header index ON and set at 5.5.
Display shows 13.5 5.5 REEL IND where 13.5 (8 + 5.5) is the reel speed in mph and 5.5 is the
header index setting.
• Windrower speed drops to 12 km/h (7.5 mph) at the same header index setting.
Display shows 13.0 5.5 REEL IND where 13.0 (7.5 + 5.5) is the reel speed in mph and 5.5 is the
header index setting.
• Windrower is operating at 13 km/h (8 mph) with header index ON and set at 1.0.
Display shows 9.0 1.0 REEL IND where 9.0 (8 + 1.0) is the reel speed in mph and 1.0 is the
header index setting.
OPERATION
19. REEL IND will only be displayed when operating at a ground speed faster than minimum reel speed plus
header index value.
