214603 299 Revision A
Figure 5.21: Operator Console
1. Place ground speed lever (GSL) (A) in N-DETENT.
2. Shut down the engine, and remove the key.
Figure 5.22: Steering Rods
3. Check steering rod bolts (A) for looseness and ball
joints (B) for any perceptible movement.
Figure 5.23: Steering Rods (Pump End)
MAINTENANCE AND SERVICING
