214603 300 Revision A
1000835
A
B
Figure 5.24: Steering Link
4. Check steering link bolts (A) for looseness and ball
joints (B) for any perceptible movement.
1000836
A
B
Figure 5.25: Steering Link
5. If bolts are loose:
a. Back off jam nut (A).
b. Tighten inside nut (B) to 95–108 Nm (70–80 lbf·ft).
c. Hold inside nut (B) and tighten jam nut (A) to
81–95 Nm (60–70 lbf·ft).
6. To replace loose steering link ball joints or steering rod ball joints, contact your MacDon Dealer.
7. After replacing parts or making adjustments, perform checks for Neutral Interlock and steering lock. Refer to
5.5.2 Safety Systems, page 295.
MAINTENANCE AND SERVICING
