214603 374 Revision A
Figure 5.162: Beacon Lamp Assembly
5. Disconnect harness from lamp.
IMPORTANT:
Do NOT touch the glass (A) of the halogen bulb as the
oils or other chemicals from your skin will cause the
bulb to fail prematurely.
Figure 5.163: Beacon Lamp Assembly
6. Connect harness to new lamp, place lamp in socket,
and line up the flat side on lamp with recess in socket.
MAINTENANCE AND SERVICING
