214603 375 Revision A
Figure 5.164: Beacon Lamp Assembly
7. Place retainer (A) over lamp and pinch tabs to secure
retainer to socket.
Figure 5.165: Beacon Lamp Assembly
8. Line up the three lugs (one is longer) in the base with
slots in lens, and seat the lens against the rubber seal.
MAINTENANCE AND SERVICING
