Codes CDM Display Description
E25 E125 DECK SHFT LEFT P96 Left deck shift solenoid P96 fault detected
E26 E126 DWA UP DWA raise solenoid P72, P73 fault detected
E27 E127 DWA DOWN DWA lower solenoid P72, P73, fault detected circuit
E28 E128 TILT RETRACT Header tilt retract solenoid P54, fault detected
E29 E129 TILT EXTEND Header tilt extend solenoid P53, P54, fault detected
E30 E130 4 WAY VALVE P62 Four-way valve solenoid P62 fault detected
E31 E131 BYPASS VALVE P52 Bypass valve solenoid P52 fault detected
E32 E132 HEADER UP/DOWN P57
Header up/down solenoid P57, fault detected
E33 E133 SCREEN CLEANERS Screen cleaner output fault detected
E34 E134 RIGHT STOP LAMP Right stop lamp output fault detected
E35 E135 LEFT STOP LAMP Left stop lamp output fault detected
E36 E136 RIGHT TURN LAMP Right turn lamp output fault detected
E37 E137 LEFT TURN LAMP Left turn lamp output fault detected
E38 E138 MAIN DRIVE Main header drive solenoid P106 fault detected
E39 E139 LOW RANGE P61 Low range solenoid P61 fault detected
E40 E140 HIGH RANGE P60 High range solenoid P60 fault detected
E41 E141 REEL AFT Reel aft solenoid P55, P59, fault detected
E42 E142 REEL FORE Reel fore solenoid P55, P59, fault detected
E43 E143 REEL UP/DOWN P58 Reel up/down solenoid P58, P52, P62 fault detected
E44 E144 FLOAT RHS P64 RHS float solenoid P64, fault detected
E45 E145 FLOAT LHS P63 LHS float solenoid P63, fault detected
E46 SENSOR VOLTS HIGH WCM’s 9V sensor voltage output high (wire CH5)
E47 SENSOR VOLTS LOW WCM’s 9V sensor voltage output low (wire CH5)
E48
WCM OVER TEMP
E49 the temp limits are set to -10C and +85C representing
the board temp read by the chip inside the WCM module; this
is to protect the module when operating at extreme temp; the
WCM outputs will stop working (they stay off) when the board
temp is below -20C or above 120C; the high temp may
indicate a strong/ massive short circuit in the cabling on the
WCM outputs
E49
WCM LOW TEMP
WCM low temp fault
E50
BATT+ OUT OF RANGE
System voltage above 15.5 VDC
E51
DISK DRIVE PWM P68
Disk header drive solenoid P68 fault detected
E52
E53 E153
REVERSER P71
Optional reverser—solenoid P71 fault detected
E54
REFERENCE
