MacDon M205 - Page 500

214603 480 Revision A
Codes CDM Display Description
E55
DISK SPD OVERLOAD
Low disk speed detected < setpoint
Error codes E56 to E63 not allocated
E64
E65
KNIFE SPD OVERLOAD
Low knife speed detected < setpoint
E66
##.# LOW VOLTS
Low system voltage <11.5 VDC
E67
TRANS OIL PRESSURE
Supercharge pressure low (switch MD #139775)
E68
HYDRAULIC OIL HOT
Oil tank temp >230°F/110°C
E69
ENGINE AIR FILTER
Engine air filter plugged
E70
HYDRAULIC FILTER Hydraulic filter pressure too high (switch MD #139722)
E71
LOW HYDRAULIC OIL Low hydraulic oil level sensor tripped (switch MD #138473)
E72
##.# HIGH VOLTS
System voltage above 15.5 VDC
Error codes E73 to E100 not allocated
E101
SPI ERROR
Indicates that the communication between the two micros
inside the WCM module is not working properly; could be
resolved by reprogramming the WCM
E102 CAN ERROR
E102 is detected by the WCM module so the issue is related
to the CANBUS signals on the WCM end; it may happen
when the CDM sees the engine ECU but not the WCM (not
hooked up or experiencing power or CANBUS problems; may
also happen if the CDM connector P38, pin 8 signal is
malfunctioning or the wire between the CDM connector P38,
pin 8 and WCM connector P36, pin 30 is not making a proper
connection). The wire at the CDM is CB60 and at the WCM
CH60
E103
EEPROM READ ERROR
Internal errors specific to the WCM; try reprogramming the
module
E104
EEPROM WRITE ERROR
Internal errors specific to the WCM; try reprogramming the
module
E105
TEMP SENSOR ERROR
Internal errors specific to the WCM; try reprogramming the
module
REFERENCE
