214603 32 Revision A
Header Flotation
Primary
adjustment
Manual, external, drawbolt with springs (1 per side)
One inner booster spring on left side
Fine adjustment Hydraulic, in-cab switch
Automatic
Hydraulic, 3 programmable settings for all headers
(deck shift compensation on draper headers)
Cab
Type
Spring/shock suspension
Dimensions Width
1600 mm (63 in.)
Dimensions
Depth
1735 mm (68.3 in.) (at top of window)
Dimensions
Height
1640 mm (64.6 in.)
Dimensions
Volume
3540 L (125 cu. ft.)
Seat
Driver Adjustable air-ride suspension, seat belt
Seat
Training Folding, cab mounted, seat belt
Windshield
wiper
Front
800 mm (31.5 in.) blade
Windshield
wiper
Rear
560 mm (22 in.) blade
Heater
7038 W (24,000 Btu/h)
Air conditioning
8288 W (28,280 Btu/h)
Electrical outlets
One live, two on ignition, one live/keyed
Mirrors
One inside (transport), two outside (field)
Radio
Two speakers and antenna factory installed: radio Dealer installed
System Monitoring
Speeds
Ground (mph or km/h), engine (rpm), knife (spm), disc (rpm), reel (rpm or
mph / km/h), conveyor (Ref. No.)
Header
Height, angle, float, header drive load gauge
Tire Options
Size
Drive
18.4 – 26 bar, 18.4 – 26 turf, 600-65 R28 bar, 23.1 – 26 turf,
580/70R26 turf
Size
Rear
7.5 – 16SL single rib, 10 – 16 front steer tire 16.5L – 16.1 rib implement
flotation, forked caster
Pressure
Drive
Refer to Inflating Drive Wheel Tire, page 399
Pressure Rear
Refer to Inflating Caster Tire, page 406
PRODUCT OVERVIEW
