R&S ZNB - Page 1303

Command Reference
R&S
®
ZNB/ZNBT
1303User Manual 1173.9163.02 ─ 55
Parameters:
<Codec> ASCii | UTF8 | SJIS
ASCii: 8-bit ANSI (default)
UTF8: UTF-8
SJIS: Shift JIS
Manual operation: See "Remote Encoding" on page 698
SYSTem:COMMunicate:GPIB[:SELF]:ADDRess <GBIBAddress>
Sets the GPIB address of the analyzer.
Parameters:
<GBIBAddress> GPIB address (integer number)
Range: 0 to 30
Example:
SYST:COMM:GPIB:ADDR 10
Set the GPIB address to 10.
*RST; :SYST:COMM:GPIB:ADDR?
After a reset, the address is maintained (the response is 10).
Manual operation: See "GPIB Address" on page 715
SYSTem:COMMunicate:GPIB[:SELF]:DCLear:SUPPress <Boolean>
Suppresses/unsuppresses of Device Clear GPIB interface messages (DCL, SDC).
Parameters:
<Boolean>
Manual operation: See "GPIB Address" on page 715
SYSTem:COMMunicate:GPIB[:SELF]:INIT:WAIT <Boolean>
Determines/queries the execution behavior of INITiate[:IMMediate] commands
(see Chapter 8.3.8, "INITiate Commands", on page 1056).
If set to ON, an automatic *WAI is added (see Chapter 8.2, "Common Commands",
on page 778), i.e. the commands execute synchronously.
Parameters:
<Boolean> *RST: OFF
Manual operation: See "Advanced ..." on page 717
SYSTem:COMMunicate:GPIB[:SELF]:LPORt:ALIGn <Boolean>
Configures/queries the logical port creation.
If set to ON, logical ports are aligned and must be set from low to high port, which was
the only possibility prior to firmware V1.90. If set to OFF, new ports can be created
freely, like in manual operation. See the example below.
SCPI Command Reference
