Controller area network (bxCAN) RM0008

670/1096 Doc ID 13902 Rev 12

Filter bank i register x (CAN_FiRx) (i=0..27 in connectivity line devices,, x=1,

Address offsets: 0x240..0x31C

Reset value: undefined

Note: In connectivity line devices there are 28 filter banks, i=0 .. 27, in other devices there are 14

filter banks i = 0 ..13. Each filter bank i is composed of two 32-bit registers, CAN_FiR[2:1].

This register can only be modified when the FACTx bit of the CAN_FAxR register is cleared

or when the FINIT bit of the CAN_FMR register is set.

In all configurations:

Note: Depending on the scale and mode configuration of the filter the function of each register can

differ. For the filter mapping, functions description and mask registers association, refer to

Section 24.7.4: Identifier filtering on page 640.

A Mask/Identifier register in mask mode has the same bit mapping as in identifier list

mode.

For the register mapping/addresses of the filter banks please refer to the Table 180 on

page 671.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

FB31 FB30 FB29 FB28 FB27 FB26 FB25 FB24 FB23 FB22 FB21 FB20 FB19 FB18 FB17 FB16

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw

1514131211109876543210

FB15 FB14 FB13 FB12 FB11 FB10 FB9 FB8 FB7 FB6 FB5 FB4 FB3 FB2 FB1 FB0

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw

Bits 31:0 FB[31:0]: Filter bits

Identifier

Each bit of the register specifies the level of the corresponding bit of the expected identifier.

0: Dominant bit is expected

1: Recessive bit is expected

Mask

Each bit of the register specifies whether the bit of the associated identifier register must

match with the corresponding bit of the expected identifier or not.

0: Don’t care, the bit is not used for the comparison

1: Must match, the bit of the incoming identifier must have the same level has specified in

the corresponding identifier register of the filter.
