Secure digital input/output interface (SDIO) RM0090

1064/1749 RM0090 Rev 18

31.9.6 SDIO response 1..4 register (SDIO_RESPx)

Address offset: (0x10 + (4 × x)); x = 1..4

Reset value: 0x0000 0000

The SDIO_RESP1/2/3/4 registers contain the status of a card, which is part of the received

response.

The Card Status size is 32 or 127 bits, depending on the response type.

The most significant bit of the card status is received first. The SDIO_RESP3 register LSB is

always 0b.

31.9.7 SDIO data timer register (SDIO_DTIMER)

Address offset: 0x24

Reset value: 0x0000 0000

The SDIO_DTIMER register contains the data timeout period, in card bus clock periods.

A counter loads the value from the SDIO_DTIMER register, and starts decrementing when

the data path state machine (DPSM) enters the Wait_R or Busy state. If the timer reaches 0

while the DPSM is in either of these states, the timeout status flag is set.

Note: A data transfer must be written to the data timer register and the data length register before

being written to the data control register.

313029282726252423222120191817161514131211109876543210

CARDSTATUSx

rrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrr

Bits 31:0 CARDSTATUSx: see Table 180.

Table 180. Response type and SDIO_RESPx registers

SDIO_RESP1 Card Status[31:0] Card Status [127:96]

SDIO_RESP2 Unused Card Status [95:64]

SDIO_RESP3 Unused Card Status [63:32]

SDIO_RESP4 Unused Card Status [31:1]0b

313029282726252423222120191817161514131211109876543210

DATATIME

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw

Bits 31:0 DATATIME: Data timeout period

Data timeout period expressed in card bus clock periods.
