RM0090 Rev 18 1405/1749
RM0090 USB on-the-go high-speed (OTG_HS)
1543
Device-mode CSR map
These registers must be programmed every time the core changes to peripheral mode.
OTG_HS_HCCHARx
0x500
0x520
...
0x660
OTG_HS host channel-x characteristics register (OTG_HS_HCCHARx)
(x = 0..11, where x = Channel_number) on page 1437
OTG_HS_HCSPLTx 0x504
OTG_HS host channel-x split control register (OTG_HS_HCSPLTx)
(x = 0..11, where x = Channel_number) on page 1439
OTG_HS_HCINTx 0x508
OTG_HS host channel-x interrupt register (OTG_HS_HCINTx) (x = 0..11,
where x = Channel_number) on page 1440
OTG_HS_HCINTMSKx 0x50C
OTG_HS host channel-x interrupt mask register (OTG_HS_HCINTMSKx)
(x = 0..11, where x = Channel_number) on page 1441
OTG_HS_HCTSIZx 0x510
OTG_HS host channel-x transfer size register (OTG_HS_HCTSIZx)
(x = 0..11, where x = Channel_number) on page 1442
OTG_HS_HCDMAx 0x514
OTG_HS host channel-x DMA address register (OTG_HS_HCDMAx)
(x = 0..11, where x = Channel_number) on page 1443
Table 209. Host-mode control and status registers (CSRs) (continued)
Acronym
Offset
address
Register name
Table 210. Device-mode control and status registers
Acronym
Offset
address
Register name
OTG_HS_DCFG 0x800
OTG_HS device configuration register (OTG_HS_DCFG) on
page 1443
OTG_HS_DCTL 0x804 OTG_HS device control register (OTG_HS_DCTL) on page 1445
OTG_HS_DSTS 0x808 OTG_HS device status register (OTG_HS_DSTS) on page 1447
OTG_HS_DIEPMSK 0x810
OTG_HS device IN endpoint common interrupt mask register
(OTG_HS_DIEPMSK) on page 1448
OTG_HS_DOEPMSK 0x814
OTG_HS device OUT endpoint common interrupt mask register
(OTG_HS_DOEPMSK) on page 1449
OTG_HS_DAINT 0x818
OTG_HS device all endpoints interrupt register (OTG_HS_DAINT)
on page 1450
OTG_HS_DAINTMSK 0x81C
OTG_HS all endpoints interrupt mask register
(OTG_HS_DAINTMSK) on page 1451
OTG_HS_DVBUSDIS 0x828
OTG_HS device V
BUS
discharge time register
(OTG_HS_DVBUSDIS) on page 1451
OTG_HS_DVBUSPULSE 0x82C
OTG_HS device V
BUS
pulsing time register
(OTG_HS_DVBUSPULSE) on page 1452
OTG_HS_DTHRCTL 0x830
OTG_HS Device threshold control register (OTG_HS_DTHRCTL)
on page 1453
