Flexible static memory controller (
FSMC)
RM0090
1570/1749
RM0090 Rev 18
Figure 449. Asynchronou
s wait during a read access
1.
NWAIT polarity depends on WAITPOL bi
t setting in
FSMC_BCRx register.
Figure 450. Asynchronous wa
it during a write access
1.
NWAIT polarity depends on WAITPOL bi
t setting in
FSMC_BCRx register.
A[25:0]
NOE
4HCLK
Memory transaction
NW
AIT
D[15:0]
NEx
data driven
by memory
ai18471b
address phase
don’t care
data setup phase
don’t care
A[25:0]
NWE
Memory transaction
NW
AIT
D[15:0]
NEx
data driven by FSMC
ai15797c
3HCLK
address phase
data setup phase
1HCLK
don’t care
don’t care
