Digital camera interface
(DCMI)
RM0090
460/1749
RM0090 Rev 18
Figure 75. T
iming diagram
ai15944b
Beginning of JPEG stream
JPEG data
DCMI_HSYNC
JPEG packet data
DCMI_VSYNC
Padding data
at the end of the JPEG stream
Programmable
JPEG packet size
End of JPEG stream
Packet dispatching depends on the image content.
This results in a variable blanking duration.
459
461
