RM0090 Rev 18
531/1749
RM0090
Advanced-control timers (TIM1 an
d TIM8)
588
Figure 106. Update ra
te examples depending on mode and
TIMx_RCR register
settings
MSv31
195V1
UEV
UEV
UEV
UEV
UEV
Counter-aligned mode
Edge-aligned mode
Upcounting
Downcounting
(by SW)
(by SW)
(by SW)
TIMx_RCR = 3
and
re-synchronization
TIMx_RCR = 3
TIMx_RCR = 2
TIMx_RCR = 1
TIMx_RCR = 0
Counter
TIMx_CNT
UEV
Update event
: Preload registers transferred to active registers and update interrupt generated
Update Event
if the repetition counter underflow occurs when the counter is equal to the auto-reload value.
530
532
