Flexible memory c
ontroller (FMC)
RM0090
1626/1749
RM0090 Rev 18
Mode C - NOR Flash - OE toggling
Figure 465. Mod
eC read access waveforms
Figure 466. ModeC wr
ite access waveforms
The dif
ferences compared with mode
1 are the toggling of NOE and the ind
ependent read
and write timings.
A[25:0]
NOE
ADDSET DA
T
AST
Memory transaction
NEx
D[31:0]
HCLK cycles
HCLK cycles
NWE
NADV
data driven
by memory
MS30459V1
High
A[25:0]
NOE
ADDSET
(DA
T
AST + 1)
Memory transaction
NEx
D[31:0]
HCLK cycles
HCLK cycles
NWE
NADV
data driven by FSMC
MS30460V1
