RM0090 Rev 18
1567/1749
RM0090
Flexible static me
mory contr
oller (FSMC)
1601
Muxed mode - multiplexed asynchronous a
ccess to NOR Flash memory
Figure 447. Multiple
xed read acce
sses
Figure 448. Multiplexed write acces
ses
The dif
ference with mode D is the drive
of the lower address byte(s
) on the databus.
A[25:16]
NOE
ADDSET
(DA
T
AST + 1)
Memory transaction
NEx
AD[15:0]
HCLK cycles
HCLK cycles
NWE
NADV
data driven by FSMC
ai15569
1HCLK
ADDHLD
HCLK cycles
Lower address
1566
1568
