ST STM32F405 User Manual

RM0090 Rev 18 987/1749
RM0090 Universal synchronous asynchronous receiver transmitter (USART)
1018
15. 7.168 MBps N.A N.A N.A N.A N.A N.A
16. 7.3728 MBps N.A N.A N.A N.A N.A N.A
17. 9 MBps N.A N.A N.A N.A N.A N.A
18. 10.5 MBps N.A N.A N.A N.A N.A N.A
1. The lower the CPU clock the lower the accuracy for a particular baud rate. The upper limit of the achievable baud rate can be
fixed with these data.
2. Only USART1 and USART6 are clocked with PCLK2. Other USARTs are clocked with PCLK1. Refer to the device
datasheets for the maximum values for PCLK1 and PCLK2.
Table 142. Error calculation for programmed baud rates at f
PCLK
= 42 MHz or f
PCLK
= 84 Hz,
oversampling by 16
(1)(2)
(continued)
Oversampling by 16 (OVER8=0)
Baud rate f
PCLK
= 42 MHz f
PCLK
= 84 MHz
S.No Desired Actual
Value
programmed
in the baud
rate register
% Error =
(Calculated -
Desired)B.Rate
/Desired B.Rate
Actual
Value
programmed
in the baud
rate register
%
Error
Table 143. Error calculation for programmed baud rates at f
PCLK
= 42 MHz or f
PCLK
= 84 MHz,
oversampling by 8
(1)(2)
Oversampling by 8 (OVER8=1)
Baud rate f
PCLK
= 42 MHz f
PCLK
= 84 MHz
S.No Desired Actual
Value
programmed
in the baud
rate register
Value
programmed
in the baud
rate register
Actual
Value
programmed
in the baud
rate register
%
Error
1. 2.4 KBps 2.4 KBps 2187.5 0 2.4 KBps NA 0
2. 9.6 KBps 9.6 KBps 546.875 0 9.6 KBps 1093.75 0
3. 19.2 KBps 19.195 KBps 273.5 0.02 19.2 KBps 546.875 0
4. 38.4 KBps 38.391 KBps 136.75 0.02 38.391 KBps 273.5 0.02
5. 57.6 KBps 57.613 KBps 91.125 0.02 57.613 KBps 182.25 0.02
6. 115.2 KBps 115.068 KBps 45.625 0.11 115.226 KBps 91.125 0.02
7. 230.4 KBps 230.769 KBps 22.75 0.11 230.137 KBps 45.625 0.11
8. 460.8 KBps 461.538 KBps 11.375 0.16 461.538 KBps 22.75 0.16
9. 921.6 KBps 913.043 KBps 5.75 0.93 923.076 KBps 11.375 0.93
10. 1.792 MBps 1.826 MBps 2.875 1.9 1.787Mbps 5.875 0.27
11. 1.8432 MBps 1.826 MBps 2.875 0.93 1.826 MBps 5.75 0.93
12. 3.584 MBps 3.5 MBps 1.5 2.34 3.652 MBps 2.875 1.9
13. 3.6864 MBps 3.82 MBps 1.375 3.57 3.652 MBps 2.875 0.93
14. 7.168 MBps N.A N.A N.A 7 MBps 1.5 2.34
15. 7.3728 MBps N.A N.A N.A 7.636 MBps 1.375 3.57
