USB on-the-go high-speed (OTG_HS) RM0090
1406/1749 RM0090 Rev 18
OTG_HS_DIEPEMPMSK 0x834
OTG_HS device IN endpoint FIFO empty interrupt mask register:
(OTG_HS_DIEPEMPMSK) on page 1454
OTG_HS_DEACHINT 0x838
OTG_HS device each endpoint interrupt register
(OTG_HS_DEACHINT) on page 1454
OTG_HS_DEACHINTMSK 0x83C
OTG_HS device each endpoint interrupt register mask
(OTG_HS_DEACHINTMSK) on page 1455
OTG_HS_DIEPEACHMSK1 0x844
OTG_HS device each in endpoint-1 interrupt register
(OTG_HS_DIEPEACHMSK1) on page 1455
OTG_HS_DOEPEACHMSK1 0x884
OTG_HS device each OUT endpoint-1 interrupt register
(OTG_HS_DOEPEACHMSK1) on page 1456
OTG_HS_DIEPCTLx
0x900
0x920
...
0x9A0
OTG device endpoint-x control register (OTG_HS_DIEPCTLx) (x =
0..5, where x = Endpoint_number) on page 1457
OTG_HS_DIEPINTx 0x908
OTG_HS device endpoint-x interrupt register
(OTG_HS_DIEPINTx) (x = 0..5, where x = Endpoint_number) on
page 1464
OTG_HS_DIEPTSIZ0 0x910
OTG_HS device IN endpoint 0 transfer size register
(OTG_HS_DIEPTSIZ0) on page 1467
OTG_HS_DIEPDMAx/
OTG_HS_DOEPDMAx
0x914/0xB14
OTG_HS device endpoint-x DMA address register
(OTG_HS_DIEPDMAx / OTG_HS_DOEPDMAx) (x = 0..5, where
x = Endpoint_number) on page 1471
OTG_HS_DTXFSTSx 0x918
OTG_HS device IN endpoint transmit FIFO status register
(OTG_HS_DTXFSTSx) (x = 0..5, where x = Endpoint_number) on
page 1470
OTG_HS_DIEPTSIZx
0x930
0x950
...
0x9B0
OTG_HS device endpoint-x transfer size register
(OTG_HS_DIEPTSIZx) (x = 1..5, where x = Endpoint_number) on
page 1469
OTG_HS_DOEPCTL0 0xB00
OTG_HS device control OUT endpoint 0 control register
(OTG_HS_DOEPCTL0) on page 1460
OTG_HS_DOEPSIZ0 0xB10
OTG_HS device OUT endpoint 0 transfer size register
(OTG_HS_DOEPTSIZ0) on page 1468
OTG_HS_DOEPCTLx
0xB20
0xB40
...
0xBA0
OTG_HS device endpoint-x control register
(OTG_HS_DOEPCTLx) (x = 1..5, where x = Endpoint_number) on
page 1461
Table 210. Device-mode control and status registers (continued)
