General purpose timers (TIM2 to TIM5):
Removed all references to “repetition counter”.
Added Figure 134: General-purpose timer block diagram.
Updated 16-bit prescaler range in Section 18.2: TIM2 to TIM5 main features.
External clock mode 2 ETR restricted to TIM2 to TIM4 in
Section 18.3.3: Clock selection and Section 18.3.6: PWM input mode.
Updated Section 18.3.9: PWM mode and Section 18.3.11: Clearing the OCxREF
signal on an external event.
Updated Figure 174: Master/Slave timer example to change ITR1 to
ITR0.
Updated read and write access to registers in Section 18.4: TIM2 to TIM5
registerss.
Restored bits 15 to 8 of TIMx_SMCR as well as Table 98: TIMx internal trigger
connection in Section 14.4.3.
Removed note 1 related to OC1M bits in Section 18.4.13: TIMx capture/compare
register 1 (TIMx_CCR1).
Updated TIMx_CCER bit description for TIM2 to TIM5 in
Section 18.4.9: TIMx capture/compare enable register (TIMx_CCER).
General purpose timers (TIM9 to TIM14):
Updated 16-bit prescaler range in Section 19.2.1: TIM9/TIM12 main features and
Section 19.2.2: TIM10/TIM11 and TIM13/TIM14 main features.
Updated Figure 181: General-purpose timer block diagram (TIM10/11/13/14)) to
remove TRGO trigger controller output.
Added register access in Section 19.4: TIM9 and TIM12 registers
and Section 19.5: TIM10/11/13/14 registers.
Basic timers (TIM6 and TIM7):
Removed all references to “repetition counter”.
Updated 16-bit prescaler range in Section 20.2: TIM6 and TIM7 main features.
HASH:
Updated Section 25.3.1: Duration of the processing.
RNG:
Updated Section 24.1: RNG introduction.
