RM0090 Revision history
1743
19-Oct-2012
2
(continued)
FSMC:
Updated step b) in Section 36.3.1: Supported memories and transactions.
Updated Table 196: FSMC_BTRx bit fields.
Changed Clock divide ration min in Table 246: Programmable NAND/PC Card
access parameters.
Updated case of synchronous accesses in Section 36.5: NOR Flash/PSRAM
controller.
Changed minimum value for ADDSET to 0 in Table 203, Table 206, Table 207,
Table 209, and Table 210.
Move note from Figure 437: Mode1 write accesses and Figure 436: Mode1 read
accesses. Move note from Figure 439: ModeA write accesses to Figure 438:
ModeA read accesses.
Updated Section : WAIT management in asynchronous accesses.
Added register access in Section 36.5.6: NOR/PSRAM control registers and
Section 36.6.2: NAND Flash / PC Card supported memories and transactions.
Removed caution note in Section 36.6.1: External memory interface signalss.
Updated Table 249: 16-bit PC Card.
Updated step 3 in Section 36.6.4: NAND Flash operations.
Updated Figure 455: Access to non ‘CE don’t care’ NAND-Flash and note below in
Section 36.6.5: NAND Flash prewait functionality.
Updated access to I/O Space in Section 36.6.7: PC Card/CompactFlash
operationss. Updated Table 251: 16-bit PC-Card signals and access type. Updated
BUSTURN bit definition in Section : SRAM/NOR-Flash chip-select timing registers
1..4 (FSMC_BTR1..4)). Changed bits 16 to 19 to BUSTURN in Section :
SRAM/NOR-Flash write timing registers 1..4 (FSMC_BWTR1..4)
DEBUG:
Updated Section 38.4.3: Internal pull-up and pull-down on JTAG pins.
Electronic signature
Updated Section 39: Device electronic signature introduction.
Updated REV_ID[15:0] to add revision Z in Section 39.1: Unique device ID register
(96 bits).
Updated address and example in Section 39.2: Flash size.
