General-purpose timers (TIM9 to TIM14) RM0090

678/1749 RM0090 Rev 18

19.4.6 TIM9/12 capture/compare mode register 1 (TIMx_CCMR1)

Address offset: 0x18

Reset value: 0x0000

The channels can be used in input (capture mode) or in output (compare mode). The

direction of a channel is defined by configuring the corresponding CCxS bits. All the other

bits in this register have different functions in input and output modes. For a given bit, OCxx

describes its function when the channel is configured in output mode, ICxx describes its

function when the channel is configured in input mode. Take care that the same bit can have

different meanings for the input stage and the output stage.

Output compare mode

1514131211109876543210

Res. OC2M[2:0] OC2PE OC2FE

CC2S[1:0]

Res. OC1M[2:0] OC1PE OC1FE

CC1S[1:0]

IC2F[3:0] IC2PSC[1:0] IC1F[3:0] IC1PSC[1:0]

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw

Bit 15 Reserved, must be kept at reset value.

Bits 14:12 OC2M[2:0]: Output compare 2 mode

Bit 11 OC2PE: Output compare 2 preload enable

Bit 10 OC2FE: Output compare 2 fast enable

Bits 9:8 CC2S[1:0]: Capture/Compare 2 selection

This bitfield defines the direction of the channel (input/output) as well as the used input.

00: CC2 channel is configured as output

01: CC2 channel is configured as input, IC2 is mapped on TI2

10: CC2 channel is configured as input, IC2 is mapped on TI1

11: CC2 channel is configured as input, IC2 is mapped on TRC. This mode works only if an

internal trigger input is selected through the TS bit (TIMx_SMCR register

Note: The CC2S bits are writable only when the channel is OFF (CC2E = 0 in TIMx_CCER).

Bit 7 Reserved, must be kept at reset value.
