Inter-integrated circuit (I2C) interface RM0090

862/1749 RM0090 Rev 18

Note: When the STOP, START or PEC bit is set, the software must not perform any write access

to I2C_CR1 before this bit is cleared by hardware. Otherwise there is a risk of setting a

second STOP, START or PEC request.

27.6.2 I

C Control register 2 (I2C_CR2)

Address offset: 0x04

Reset value: 0x0000

Bit 2 Reserved, must be kept at reset value

Bit 1 SMBUS: SMBus mode

0: I

C mode

1: SMBus mode

Bit 0 PE: Peripheral enable

0: Peripheral disable

1: Peripheral enable

Note: If this bit is reset while a communication is on going, the peripheral is disabled at the

end of the current communication, when back to IDLE state.

All bit resets due to PE=0 occur at the end of the communication.

In master mode, this bit must not be reset before the end of the communication.

1514131211 10 9 8 76543210

Reserved

LAST DMAEN ITBUFEN ITEVTEN ITERREN

Reserved

FREQ[5:0]

rw rw rw rw rw rw rw rw rw rw rw

Bits 15:13 Reserved, must be kept at reset value

Bit 12 LAST: DMA last transfer

0: Next DMA EOT is not the last transfer

1: Next DMA EOT is the last transfer

Note: This bit is used in master receiver mode to permit the generation of a NACK on the last

received data.

Bit 11 DMAEN: DMA requests enable

0: DMA requests disabled

1: DMA request enabled when TxE=1 or RxNE =1

Bit 10 ITBUFEN: Buffer interrupt enable

0: TxE = 1 or RxNE = 1 does not generate any interrupt.

1: TxE = 1 or RxNE = 1 generates Event Interrupt (whatever the state of DMAEN)
