Chapter 6
Adjustment and verification
P/N 57150002, Revision 5.0 6 - 55 Trimble S, VX, SPS & RTS Service Manual
F
Fig. 6-47 Laser pointer adjustment
Fig. 6-48 Transmitter spot on screen attachment
Item Performance Description Result Notes
EDM fixing screws A & C
70 Ncm /
6.20 lbfin
Illuminated screen
Shadow of the transmitting prism
Transmitter laser spot
