Chapter 6
Adjustment and verification
P/N 57150002, Revision 5.0 6 - 93 Trimble S, VX, SPS & RTS Service Manual
F
Fig. 6-101 Adjustment Transmitter/Laser pointer
Collimator 79592001
3 Fibre adjustment
Preparation.
Adjust the light intensity
by moving the Greyfilter.
Fig. 6-102 Adjust attenuator Greyfilter TX
GDM collimator T71601480
3 Fibre adjustment
Preparation.
Adjust the light intensity
by moving the Greyfilter.
Item Performance Description Result Notes
Greyfilter
