Chapter 6
Adjustment and verification
Trimble S, VX, SPS & RTS Service Manual6 - 96 P/N 57150002, Revision 5.0
F
Fig. 6-106 EDM frame adjustment
Fig. 6-107 Transmitter spot on screen attachment
Item Performance Description Result Notes
70 Ncm /
6.20 lbfin
Horizontal
Vertical
Movement of
EDM frame
A&C
Transmitter laser beam
Shadow of the Transmitter prism
Forbidden reflection
Illuminated screen
