Trimble S User Manual

Chapter 6
Adjustment and verification
Trimble S, VX, SPS & RTS Service Manual6 - 124 P/N 57150002, Revision 5.0
F
7 Measure baselines. A. Select Offset
determination
check
box.
B. Click
Start offset det.
button, see Fig. 6-136
on page 6-123 .
C. A message box with
the properties of the
first baseline in the list
appears.
D. Aim to the target and
click
Set Hz
orientation
.
E. Click
Measure, Fig. 6-
138 on page 6-125 is
displayed.
F. Click
Position to
position instrument to
the next target.
Selected baselines
will be displayed.
Fig. 6-137 Message box Release Measurement)
Item Performance Description Result Notes
effects that all following
measurements will be cancelled,
the offset determination is terminated
allows to skip a baseline in the
list and continue to the next
positions the instrument to
the next target, ONLY if the angles to the
click this button on the
first target and when clicking Position
the software will automatically position
the instrument to the next target
the distance
to the DR target or prism
a help to position
the instrument
targets are set in the baseline editor
Cancel
Skip
Position
Position offset
Measure
Laser pointer
