Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only I – 1
Index
Index
A
AC inlet
MFP, 1-7
SFP, 1-6
AC Inlet Switch
part number, MFP, 9-38
part number, SFP, 9-32
AC power
requirements and consumption, 1-21
troubleshooting, 4-67
AC Power Inlet removal
MFP, 8-155
SFP, 8-131
Acronyms and Abbreviations, A-18
Actuator
ADF document sense, 2-67
Manual Feed no paper, 2-27
removal, 8-82
no paper sensor, Tray 2
removal, 8-188
Optional Feeder registration input, removal, 8-185
registration in, 2-30
part number, 9-19
Registration Input
removal, 8-77
registration out, 2-30
registration roller, 2-30
removal, 8-75
scanner home position, 2-61
Tray 1 no paper, 2-22
part number, 9-19
removal, 8-84
Tray 2 no paper, 2-24
part number, 9-58
ADC, 2-7
toner density, 2-44
ADC Sensor, 2-31
control function, 2-45
operation, 2-31
ADF
board, 2-65
components, 2-65
Cover Open Sensor, 2-65
Document Sensor, 2-65
Document Stopper, 2-66
Drive, 2-69
Feed Roll & Separator Roll Kit
part number, 9-45
Feed Roll removal, 8-13
Feed Sensor, 2-65
Media Path, 2-67
operation, 2-67
Pinch Roller Assembly, 2-66
sensors, 2-19
Separator Pad removal, 8-14
Tray Assy part number, 9-45
ADF Assembly
part number, 9-45
removal, 8-192
ADF Cover, 1-7
ADF Cover Sensor, 4-62
ADF Feed Sensor, 4-61
ADF Input Tray
removal, 8-191
ADF Motor, 2-65, 2-69
test, 4-65
ADF Tray Sensor, 4-60
Adjustments, 6-2 to 6-5
color registration, 6-2
setting parameters, 6-7
Auger, 2-8
Automatic Document Feeder - See ADF
B
Background contamination, 5-30
Banding, 5-17
Bias Transfer Roller, 2-10
Black print, 5-13
Blank prints, 5-10
Boot firmware
update, A-16
Boot sequence, 4-5
Buttons, Control Panel
diagnostic functions, 4-7
MFP functions, 1-11
SFP functions, 1-10
C
Calibrations, 6-6
Cassette Stopper
part number, 9-17, 9-56
removal, MFP, 8-47
removal, SFP, 8-32
Chase page, 5-43
Cleaning tools, 7-2
Clearances, 1-26
Clutch
registration, 2-28
Color registration, 2-45
adjustment, 6-2
alignment error, 5-4
auto adjustment, 6-4
manual adjustment, 6-4
troubleshooting, 5-37
Configuration page, A-4
