User's Manual 12. Network Connections

Version 4.4.0 211 MP26x/MP27x

12.3.8 PPTP Tab

The PPTP tab displays the PPTP settings.

Note: This tab is applicable only to PPTP connections.

Figure 12-82: Editing Connection - PPTP Tab

Table 12-5: PPTP Tab Parameter Descriptions

Parameter Description

PPTP Server Host

Name or IP Address

PPTP server host name or IP address provided by your ISP.

Default Chapter3
