User's Manual 212 Document #: LTRT-23510
MP-26x/MP-27x Multimedia Home Gateway
12.3.9 Advanced Tab
The Advanced tab provides various advanced configurations.
Figure 12-83: Editing Connection - Advanced Tab (For Example, WAN Ethernet)
Internet Connection Firewall: Your device's firewall helps protect your computer by
preventing unauthorized users from gaining access to it through a network such as the
Internet. The firewall can be activated per network connection. To enable the firewall
on this network connection, select the 'Enabled' check box. You can click the Internet
Connection Firewall link to access the ‘Security’ screen (see Section
14.1 on page
254).
Additional IP Addresses: You can also add alias names (additional IP addresses) to
the device, by clicking the New icon. This enables you to access the device using
these aliases in addition to the default IP addresses.
Figure 12-84: Additional IP Address Settings Screen
