User's Manual 272 Document #: LTRT-23510
MP-26x/MP-27x Multimedia Home Gateway
14.8 Viewing Current Connections
The connection list displays all the connections that are currently open, as well as various
details and statistics. You can use this list to close an undesired connection by clicking its
corresponding action icon. The basic display includes the name of the protocol, the
different ports it uses, and the direction in which the connection was initiated.
To view currently open connections:
1. From the menu bar, click the Security menu, and in the screen 'Security', click the
Connections tab; the screen 'Connections' opens.
2. From the Connections Per Page drop-down list, select the number of connections that
you want displayed per page. To browse to the next page, click the icon or the
page number located at the bottom left of the page.
Figure 14-24: Connections Screen
To display additional details in the Connection list, click the Advanced button.
The 'Approximate Max. Connections' value displays the amount of additional concurrent
connections possible.
