13.4.2.1 Configuring the Device via TR-069 and TR-104
TR-069 allows basic configuration of the device. The configuration is defined in a
hierarchical tree-like structure according to the TR-069 standard.
13.4.2.1.1 Configuring the WAN Interface
Table 13-6: InternetGatewayDevice.WANDevice.i.WANConnectionDevice.i.WANIPConnection.i
TR-069/TR-104
Parameter
Configuration File
Parameter
Description
AddressingType mt_cwmp_param_wan_con
n_ip_addressing_type_get/
set
The method used to assign an address to the
WAN side interface of the CPE for this
connection:
 “DHCP”
 “Static”
ConnectionStatus mt_cwmp_param_wan_con
n_ip_status_get
Current status of the connection:
 “Unconfigured”
 “Connecting”
 “Connected”
 “PendingDisconnect”
 “Disconneting”
 “Disconnected”
ConnectionType mt_cwmp_param_wan_con
n_ppp_type_get
Specifies the connection type of the
connection instance:
 “Unconfigured”
 “IP_Routed”
 “DHCP_Spoofed”
 “PPPoE_Bridged”
 “PPPoE_Relay”
 “PPTP_Relay”
 “L2TP_Relay”
DefaultGateway mt_cwmp_param_wan_con
n_ip_default_gateway_get/
set
The IP address of the default gateway for this
connection. This parameter is configurable
only if the AddressingType is Static.
DNSEnabled mt_cwmp_param_wan_con
n_ip_dns_enabled_get/set
Whether or not the device should attempt to
query a DNS server across this connection.
DNSOverrideAllowed mt_cwmp_param_wan_con
n_ip_dnsoverrideallowed_
get/set
Whether or not a manually set, non-empty
DNS address can be overridden by a DNS
entry received from the WAN.
DNSServers mt_cwmp_param_wan_con
n_xxx_dnsservers_get/set(
i)
Comma-separated list of DNS server IP
addresses for this connection. Support for
more than three DNS Servers is optional.
Enable mt_cwmp_param_wan_con
n_xxx_enable_get/set(1)
Enables or disables the connection instance.
On creation of a WANIPConnection instance,
it is initially disabled.
ExternalIPAddress mt_cwmp_param_wan_con
n_xxx_externalip_get(i)
The external IP address used by NAT for this
connection. This parameter is configurable
only if the AddressingType is Static.
