User's Manual 8. Setting up your Device
Version 4.4.0 87 MP26x/MP27x
8.2.3 Quitting Automatic Dialer for Manual Configuration
If, for any reason, you need to manually configure the Internet connection, you first need to
stop the Automatic Dialer feature and then manually configure the connection, as
described below,
To quit Automatic Dialer and manually configure the Internet connection:
1. Power off the MP-264.
2. Disconnect the WAN xDSL or Ethernet cable.
3. Power on the device.
4. Wait for the Automatic Dialer process to end (i.e., the Broadband LED stops blinking).
5. Log in to the device's Web interface.
6. Manually configure the Internet connection using the 'Quick Setup' screen (see
Section 8.1 on page 73). This ensures that the Automatic Dialer feature does not re-
activate itself after the device resets.
Once the device successfully connects to the Internet, it downloads its configuration file
from the user-defined server on which the file is located.
Note: The configuration file must include the following parameter to indicate that
Automatic Dialer is no longer needed: auto_dialer_detect/done = 1.
