User's Manual 36 Document #: LTRT-23510
MP-26x/MP-27x Multimedia Home Gateway
3.1.2.2 Rear-Panel LEDs Description
The LEDs on the rear panel are described in the table below:
Table 3-5: Rear-Panel LEDs Description
LED Color State Description
xDSL Green
On xDSL physical link is up
Slow Blinking xDSL link is synchronizing
Fast Blinking xDSL attempting to train (establishing a connection with
the Internet Service Provider)
- Off No physical xDSL link
LAN / WAN Yellow
Slow Blinking Connected at 10 Mbps
Fast Blinking Connected at 100 Mbps
Steady On Connected at 1000 Mbps
Green
Blinking Activity - there is traffic
Steady On There is no activity
- Both Off Disconnected
Phone Green
On Phone is off-hook
Slow Blinking Phone is ringing
Fast Blinking The device is currently being upgraded
- Off Phone is on-hook and not ringing
USB Green
On USB device is connected
- Off No USB device is connected
