User's Manual 24 Document #: LTRT-23510

MP-26x/MP-27x Multimedia Home Gateway

The device is available in the following models:

Table 1-1: Available Models

*When Ethernet WAN is used, the number of LAN ports is reduced to 3.

Notes:

• FE refers to Fast Ethernet.

• The WAN Ethernet is the “last” port (4th in MP-262/4 and 5th in

MP-263/MP-272). It automatically turns into a LAN port when the DSL is in

use.

Model WAN Access LAN Wi-Fi FXS DECT USB 2.0 Bluetooth

MP-262

VDSL2 /

ADSL2+/ Eth

WAN

4 x FE* 802.11b/g/n 2 - 2 -

MP-262-DB

VDSL2 /

ADSL2+/ Eth

WAN

4 x FE* 802.11b/g/n 2 √ 2

√

MP-264

VDSL2 /

ADSL2+/ GbE

WAN

4 x GbE* 802.11b/g/n 2 - 2

MP-264-DB

VDSL2 /

ADSL2+/ GbE

WAN

4 x GbE* 802.11b/g/n 2 √ 2

√

MP-263

VDSL2 /

ADSL2+/ GbE

4 x FE 802.11b/g/n 2 - 2 -

MP-263-DB

VDSL2 /

ADSL2+/ GbE

4 x FE 802.11b/g/n 2 √ 3 √

MP-272

GbE WAN 4 x FE 802.11b/g/n 2 - 2 -

MP-272-DB

GbE WAN 4 x FE 802.11b/g/n 2 √ 2 √
