User's Manual 17. Add-On Servers and Disk Management
Version 4.4.0 331 MP26x/MP27x
8. Click Add; the new printer appears in the 'Print & Fax' screen.
Figure 17-43: Print & Fax – New Samba Printer
17.3.2.3 Line Printer Daemon (LPD)
This section describes how to connect computers to the device printers, using the LPD
protocol.
17.3.2.3.1 Setting Up an LPD Printer on Windows
Before configuring the LPD protocol on a LAN PC, ensure that a print driver for the specific
printer is installed.
Note: The following configuration must be applied to each LAN PC individually in
order to use the network printer.
To set up an LPD printer on Windows:
1. On your Windows computer connected to the device, from the Start menu, point to
Settings, then Printers and Faxes, and then click Add Printer; the Add Printer
Wizard starts.
2. Click Next to proceed with the wizard sequence.
3. Select 'Local printer attached to this computer' and then click Next.
To Next Page
