LED Color State Description

Red

Flashes (3 times) Attempting to register more than the allowed

number of handsets to the base unit (i.e., more than

five).

Amber

Flashing Handset is being paged. To page (locate) the

handset, see Section 25.12 on page 416.

Off DECT is disabled.

Bluetooth Red

Solid Bluetooth is enabled but no device is connected.

Red

Flashing Malfunction in device.

Green

Solid Bluetooth is enabled and a mobile device is

connected.

Green

Slow Flashing Bluetooth is ‘Discoverable’.

Green

Fast Flashing Phone booth synchronization is in process.

- Off Bluetooth is disabled.

Note: When the device is powered-up, the Status, Broadband and Phone LEDs are all

lit in red for a few seconds and then green. The Status LED remains lit in red.
