Barco S3 User Manual

6. EM GUI orientation
Image 6-15
Examples of va lid 3D* Inputs:
Image 6-16
(*) S3D inputs w ill be supported in a future software release.
Input connector colors
Not assigned and no input signal is detected
Not assigned to any Source or an input, but a signal has been detected
Assigned to a s ource or an input and an input s ignal is detected
Assigned to a source or an input, but an input signal is not detected
Input configuration menu description
Input configuration menu is accessed by clicking on the Input tab.
108 R5905948 EVENT MASTER DEVICES 17/07/2017
