DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
111
• Add to group - Add a candidate to a group. Clicking this option will reveal the following dialog box for the user
to enter a password for authentication from the Candidate Switch before being added to the SIM group. Click
OK to enter the password or Cancel to exit the dialog box.
Figure 4-96 Input password Window
• Property - To pop up a window to display the device information.
Menu Bar
The Single IP Management window contains a menu bar for device configurations, as seen below.
Figure 4-97 Menu Bar of the Topology View
File
• Print Setup - This will view the image to be printed.
• Print Topology - This will print the topology map.
• Preference - This will set display properties, such as polling interval, and the views to open at SIM startup.
Group
• Add to group - Add a candidate to a group. Clicking this option will reveal the following dialog box for the user
to enter a password for authentication from the Candidate Switch before being added to the SIM group. Click
OK to enter the password or Cancel to exit the dialog box.
Figure 4-98 Input password Window
• Remove from group - Remove an MS from the group.
Device
• Configure - This will open the Web manager for the specific device.
View
• Refresh - Update the views with the latest status.
• Topology - Display the Topology view.
Help
• About - Will display the SIM information, including the current SIM version.
