DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
565
Click the Clear All button to clear all the MPLS LDP neighbor information.
MPLS Global Settings
This window is used to display and configure the global MPLS settings.
To view the following window, click MPLS > MPLS Global Settings, as shown below:
Figure 11-7 MPLS Global Settings Window
The fields that can be configured for MPLS Global Settings are described below:
Parameter Description
MPLS Global State
Select to globally enable or disable the MPLS feature here.
LSP Trap State
Select to enable or disable the MPLS LSP trap feature here.
Click the Apply button to accept the changes made.
The fields that can be configured for MPLS Interface Settings are described below:
Parameter Description
Interface VID
Enter the interface VLAN ID that will be used here. The range is from 1 to 4094.
MPLS State
Select to enable or disable the MPLS feature for the specified interface here.
Click the Apply button to accept the changes made.
Click the Find button to locate a specific entry based on the information entered.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
MPLS LDP Interface Settings
This window is used to display and configure the MPLS LDP interface settings.
To view the following window, click MPLS > MPLS LDP Interface Settings, as shown below:
